2nd-Gen Native Vertical Shooting
Joystick Mode Switch Zoom/Gimbal Control
Teflon-Coated Axis Arms Smoother Balancing
3Kg (6.6Lbs) Payload Capacity Extended Tilt Axis
Rsa Communication Port Extensive Control Ecosystem
High-Capacity Battery Grip Approx. 2.5X Battery Runtime [1]
Purchase DJI RS 4 online at the official DJI Store to enjoy DJI expert help, One-on-one exclusive customer service, professional technical support, free shipping, 1% DJI Credit back on your purchase, and more.
Quick Launch:
Check out the video:
2nd-Gen Native Vertical Shooting
DJI RS 4 features a newly designed horizontal plate, enabling the second generation of native vertical shooting for faster and simpler operation. Without the need for additional accessories, you can simply release the horizontal plate and secure it into the vertical position for an easy switch to vertical shooting. [2]
Check out the video:
2nd-Gen Automated Axis Locks
The automated axis locks allow RS 4 to quickly start working or enter sleep mode, significantly enhancing shooting, transition, and storage efficiency. Additionally, the axis locks have smaller gaps when locked, further reducing gimbal shake.
DJI Smoothest Balancing Experience Yet
Check out the video:
DJI RS 4 features a Teflon coating for all three axes, resulting in reduced friction and smoother balancing.
When switching cameras or lenses, the fine-tuning knob on the tilt axis can move the camera forward or backwards, achieving precise, millimeter-level balancing.
The upper quick-release plate has an added adjustable placement guide to ensure secure camera mounting.
Check out the video:
Automatic Screen Lock
The OLED touchscreen incorporates a new auto-lock feature. Once locked, the screen will display the current gimbal and joystick modes at a low brightness. This not only prevents accidental touches but also helps to conserve battery power.
See for Yourself
Powerful Stabilization
Get a Feel for What It'S Like to Own DJI Rs 4 in Advance
Click and drag the image to view.
Take a Closer Look From Every Angle
Use your iOS camera to scan the QR code for an AR preview of DJI RS 4.
Excellent Payload Capacity
The lightweight body boasts a 3kg (6.6lbs) payload capacity. It can carry mainstream mirrorless camera and lens combinations, enabling comfortable holding with robust power.Compared with the previous generation, RS 4's tilt axis has been extended by 8.5 mm, offering expanded balancing space. This allows you to mount mainstream mirrorless camera and lens combinations along with accessories like ND filters, broadening the scope for creative potential.
Check out the video:
4th-Gen Rs Stabilization Algorithm
DJI has comprehensively optimized the next-generation RS stabilization algorithm for different usage scenarios. It strikes a superior balance between stabilization strength and the tactile feel of camera movement, delivering both excellent performance and an enhanced user experience. Additionally, RS 4 offers significantly improved stability when vertical shooting, easily steadying dynamic shots like running or low-angle perspectives.
Professional Creation
Check out the video:
DJI RS 4 supports the professional-grade features of DJI PRO products, delivering superior performance that makes solo creation more efficient.
Check out the video:
Bluetooth Wireless Control
DJI RS 4 can remotely control camera shutter and lens zoom with Dual-Mode Bluetooth technology. In zoom control mode, you can use the joystick to control Power Zoom for PZ lenses and Clear Image Zoom, [3] obtaining a native zoom experience. A camera only needs to be paired once, after which it can reconnect seamlessly and automatically.
Check out the video:
Support for DJI Focus Pro Motor
When paired with the new DJI Focus Pro Motor, [4] DJI RS 4 allows you to control the lens focus via dial or adjust the lens zoom via joystick. This smooth operation enables efficient lens control.
30 % increase in motor speed [5]
15 mm universal rod
Trigger Function Customization
The trigger function can be customized to FPV mode, where pressing and holding the trigger makes the gimbal's three axes follow the direction of the grip's movement. This is particularly useful for shooting rotational footage or simulating POV.
Gimbal Mode Switch
By toggling the gimbal mode switch, you can quickly switch between PF, PTF, and FPV modes. You can also set FPV mode to 3D Roll 360 mode or Custom mode according to the shooting requirements, ensuring RS 4 is precision-ready.
Intelligent Features
Check out the video:
Motionlapse
Check out the video:
Track
Check out the video:
Panorama
Rsa Communication Port
DJI RS 4 introduces an RSA communication port, which allows for the connection of accessories such as the DJI RS Tethered Control Handle [6] and third-party accessories like control handles [6] and remote-control ring handles. [6] You can flexibly switch between different shooting setups according to your creative needs.Thanks to DJI RS SDK protocol, third-party manufacturers and individual developers can develop customized functions for RS 4, meeting a wider range of shooting requirements.
DJI Rs BG70 High-Capacity Battery Grip
The new BG70 High-Capacity Battery Grip [6] can extend RS 4's battery runtime to 29.5 hours. [7] It also supports powering your camera and accessories with up to 18 W via the USB-C port at the bottom.
Support for DJI Ronin Image Transmitter
Both independent cinematographers and small crews can utilize the DJI Ronin Image Transmitter [6] for high-definition live feeds, remote gimbal and camera control, ActiveTrack 4.0, Force Mobile, and more, achieving an integrated shooting experience with monitoring and control capabilities.
DJI Rs BG30 Battery Grip
The DJI RS BG30 Battery Grip can power RS 4 for approximately 14 hours. [7] It supports PD and QC 2.0 fast charging protocols. With a 24W charging specification, it can be charged to approximately 80% in 1 hour and fully charged in 1.5 hours, and can be charged separately from the gimbal.
DJI Rs Twist Grip Dual Handle
The handle features NATO ports and a quick-release design. It allows for swift transitions from dual-handheld to low-angle briefcase configurations without the need for disassembly. It is compatible with accessories that have the corresponding ports.
DJI Rs Tethered Control Handle
In the dual-grip configuration (used with the Twist Grip Dual Handle), the handle supports operations such as entering sleep mode, recording, and focusing. Equipped with a NATO port and a cold shoe, it allows for mounting a remote monitor and adding a focus wheel on the side.
DJI Ronin Image Transmitter
It supports high-definition live feeds, remote gimbal and camera control, ActiveTrack 4.0, Force Mobile, and many other features, providing an integrated monitoring and control experience for solo cinematographers and small crews.
DJI RS 4: Gripping Storytelling
- 2nd-Gen native vertical shooting
- Joystick mode switch for zoom/gimbal control
- Teflon-Coated axis arms for smoother balancing
- 3Kg (6.6lbs) payload capacity with extended tilt axis
- Rsa communication port for extensive control ecosystem
- High-Capacity battery grip for approx. 2.5x battery runtime
